KP Presostatlar / KP35
%51
2.007,87 TL
983,86 TL
101,99 TL den başlayan taksitlerle!!
-0.2 -> 7.5 bar, G1/4A, Otomatik resetli, IP30
| TYPE CODE | KP35 |
| WEIGHT | 0.304 Kg |
| AMB. TEMP. NOTE | 80 °C/176 °F for max 120 min |
| AMBIENT TEMP. | -40 - 65 °C |
| AMBIENT TEMP. | -40 - 149 °F |
| APPROVAL | c UL us UL353, CS C22.2, c UL us UL873, CS C22.2, CCC, CE, EAC, LVD, PZH, RINA, RMRS, RoHS China |
| CONTACT FUNCTION | SPDT |
| CONTACT RATING | AC1=16 A, 400 V |
| CONTACT RATING | AC15=10 A, 400 V |
| CONTACT RATING | AC3=16 A, 400 V |
| CONTACT RATING | DC13=12 W, 220 V |
| CONTACT RATING | LR=112 A, 400 V |
| DIFF. | 0,70 - 4,00 bar |
| DIFF. | 10,00 - 58,00 psi |
| EAN NO. | 5702423146642 |
| ELECTR. CONN. | Rubber cable gland |
| ELECTR. CONN. SIZE | 6-14 mm |
| EN 60947 ELECTRICAL PROPERTIES | Insulation: 400V |
| EN 60947 ELECTRICAL PROPERTIES | Pollution degree: 3 |
| EN 60947 ELECTRICAL PROPERTIES | Rated impulse voltage: 4 kV |
| EN 60947 ELECTRICAL PROPERTIES | Short circuit prot, fuse: 16A |
| EN 60947 WIRING PROPERTIES | Flex, ferrules: 0.5-1.5 mm2 |
| EN 60947 WIRING PROPERTIES | Flex, no ferrules: 0.7-2.5 mm2 |
| EN 60947 WIRING PROPERTIES | Solid/stranded: 0.75-2.5 mm2 |
| ENCLOSURE RATING | IP30 |
| NEMA RATING (~) | 1 |
| MAX. TEST PRESSURE | 22,0 bar |
| MAX. TEST PRESSURE | 319,0 psig |
| MAX. WORKING PRESSURE | 17,0 bar |
| MAX. WORKING PRESSURE | 245 psig |
| PACK FORMAT | Multi pack |
| PRESSURE CONN. STD. | ISO 228-1 |
| PRESSURE CONN. TYPE | G - 1/4 Male |
| PRESSURE SENSING ELEM. | Bellows |
| PRODUCT ACCESSORIES | Switches accessories |
| PROD. DESCRIPTION | Pressure switch |
| PROD. GROUP | Switches and thermostats |
| PROD. NAME | Pressure switch |
| PACK QTY. | 36 PC |
| REGUL. RANGE | 6 inHg - 108 psig |
| REGUL. RANGE | -0,20 - 7,50 bar |
| RESET | AUTO |
| SERVICEABLE | No |
| UL APPROVAL FILE NAME | E31024 |
| UL APPROVAL FILE NAME | MH27572 |
